The pins of the connector can be coated with gold color and it works like a better conductor as compared with copper. So that cable can be protected from the interference of signal. The length of the connector defends the video signals from dropping quality, so short cables need to use as much as possible. The popular brands of VGI connectors are cable power, RS Pro, Matrox & StarTech. The quality of the connector can be decided through the brand name that will affect the quality a lot. The selection of a VGA connector can be done based on different parameters like the following. The price of these cables ranges from low to high like 10$ to 400$ for each connector. There are different cables used for different purposes based on the requirement. These connectors are available at different prices depending on the type & length. In addition, these cables include shielding either double or triple.

USB TO VGA CONNECTOR PS2

Alternatively, the next connectors are HD15 female, HD15 male, HD 15 female or 6PIN Mini-Din PS2 male, 4BNC male, 5BNC female, HD 15 female or USE B male cables. So, these types are normally called ‘connector one’. The male connector’s best examples are DB13W3, HD15, 5BNC, 4BNC, etc.

Alternate names of VGA connectors are the RGB connector, Mini 015, HD15, Mini D15, HDB-15, DB15 & Mini sub D15. There are different types of VGA connectors available in the market. Based on the system setup, some pins will not appear. The identification of VGA cables can be done by observing the plug inside because most of the VGA connectors include 14-pins by showing the 15th hole. The plug inside includes different pins in three tows which are placed into the holes within the computer backside. Usually, a VGA connector includes a screw-on any face of the plug for connecting it to a similar plug on the computer’s backside. Data Signal is an I2C data channel used for DDC data.Type of connector is – Computer Analog Video.The features & specifications of the VGA connector include the following. Pin15 (ID3 / SCL): Monitor ID Bit-3 or I2C data clock.Pin12 (ID1 / SDA): Monitor ID Bit-1 / Data line with I2C bi-directional.Pin11 (ID0 / RES): Monitor ID Bit0 or Reserved.

Pin9 (KEY): +5V DC output from graphic card.Pin4 (ID2 / RES) : Monitor ID Bit-2 or Reserved.Pin1 (RED): Red video (75 ohm, 0.7V peak-to-peak).The pin configuration of a VGA Connector includes 15 pins where each pin & its function is discussed below.
